ASUS PRIME B860-PLUS-CSM Motherboard

✅ In Stock
🚚 Ships in 24–48 hours

ASUS PRIME series motherboards are expertly engineered to unleash the full potential of the latest Intel(R) Core(TM) Ultra Processors (Series 2). Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the PRIME B860-PLUS-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It?s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.

Build Includes

  • 🔒 100% Sealed & Genuine Product
  • 🔄 Easy Returns
  • 🚚 Free & Safe Shipping
  • 📸 Sealed Product Pictures Shared Pre-shipping
  • Clean Cable Management
  • 🔒 100% Sealed & Genuine Product
  • 🔄 Easy Returns
  • 🚚 Free & Safe Shipping
  • 📸 Sealed Product Pictures Shared Pre-shipping
  • Clean Cable Management
  • 🔒 100% Sealed & Genuine Product
  • 🔄 Easy Returns
  • 🚚 Free & Safe Shipping
  • 📸 Sealed Product Pictures Shared Pre-shipping
  • Clean Cable Management
PRODUCT OVERVIEW
  • CPU: Support Intel(R) Core(TM) Ultra Processors (Series 2) , LGA1851
  • Supports Intel(R) Turbo Boost Technology 2.0 and Intel(R) Turbo Boost Max Technology 3.0
  • Refer to https://www.asus.com/support/download-center/ for CPU support list.
  • Intel(R) Turbo Boost Max Technology 3.0 support depends on the CPU types
  • Chipset: Intel(R) B860 Chipset
  • Memory: 4 x DIMM slots, max. 256GB, DDR5
  • Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)
  • Dual channel memory architecture
  • DIMM Fit
  • Supports Intel(R) Extreme Memory Profile (XMP) memory module
  • ASUS Enhanced Memory Profile III (AEMP III)
  • Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.
  • Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
  • Graphics: 1 x DisplayPort
  • 1 x HDMI(TM) port
  • 1 x USB 20Gbps port (USB Type-C(R)) supports DisplayPort video output
  • Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
  • Supports max. 4K@60Hz as specified in DisplayPort 1.4.
  • Supports 4K@60Hz as specified in HDMI 2.1.
  • Supports max. 4K@120Hz as specified in DisplayPort 1.4.
  • VGA resolution support depends on processors’ or graphic cards’ resolution.
  • While installing the operating system, please ensure that your monitor is
  • connected to the HDMI port on the back I/O panel or to a discrete graphics card.
  • Expansion Slots: Intel(R) Core(TM) Ultra Processors (Series 2)
  • 1 x PCIe 5.0 x16 slot
  • Intel(R) B860 Chipset
  • 1 x PCIe 4.0 x16 slot (supports x4 mode)
  • – To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals
  • Storage: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
  • Intel(R) Core(TM) Ultra Processors (Series 2)
  • M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
  • Intel(R) B860 Chipset
  • M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
  • M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  • 4 x SATA 6Gb/s ports
  • Intel(R) Rapid Storage Technology supports SATA RAID 0/1/5/10
  • Ethernet: 1 x Realtek 2.5Gb Ethernet
  • ASUS LANGuard
  • Wireless & Bluetooth: M.2 slot only (Key E, CNVi & PCIe)
  • Wi-Fi module is sold separately
  • USB: Rear USB (Total 6 ports)
  • 1 x USB 20Gbps port (1 x USB Type-C(R) with DP Alt mode)
  • 2 x USB 10Gbps ports (2 x Type-A)
  • 1 x USB 5Gbps port (1 x Type-A)
  • 2x USB 2.0 ports (2 x Type-A)
  • Front USB (Total 7 ports)
  • 1 x USB 5Gbps connector (1 x USB Type-C(R))
  • 1 x USB 5Gbps header supports additional 2 USB 5Gbps ports
  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
  • USB Type-C(R) power delivery output: max. 5V/3A
  • Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
  • – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • – Supports up to 24-Bit/192 kHz playback
  • Audio Features
  • – Audio Shielding
  • – Premium audio capacitors
  • – Dedicated audio PCB layers
  • A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output
  • Back Panel I/O Ports: 1 x USB 20Gbps port (1 x USB Type-C(R) with DP Alt mode)
  • 2 x USB 10Gbps ports (2 x Type-A)
  • 1 x USB 5Gbps port (1 x Type-A)
  • 2 x USB 2.0 ports (2 x Type-A)
  • 1 x DisplayPort
  • 1 x HDMI(TM) port
  • 1 x Realtek 2.5Gb Ethernet port
  • 3 x Audio jacks
  • Internal I/O Connectors: Fan and Cooling related
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 4 x 4-pin Chassis Fan headers
  • Power related
  • 1 x 24-pin Main Power connector
  • 1 x 8-pin +12V CPU Power connector
  • Storage related
  • 3 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
  • USB
  • 1 x USB 5Gbps connector (supports USB Type-C(R))
  • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  • 2 x USB 2.0 header support 4 additional USB 2.0 ports
  • Miscellaneous
  • 3 x Addressable Gen 2 headers
  • 1 x Aura RGB header
  • 1 x Clear CMOS header
  • 1 x Chassis Intrusion header
  • 1 x COM Port header
  • 1 x Front Panel Audio header (F_AUDIO)
  • 1 x S/PDIF Out header
  • 1 x SPI TPM header (14-1pin)
  • 1 x 10-1 pin Front System Panel header
  • 1 x Thunderbolt(TM) (USB4(R)) header
  • Special Features: ASUS 5X PROTECTION III
  • -DIGI+ VRM (- Digital power design with DrMOS)
  • – LANGuard
  • – Overvoltage Protection
  • – SafeSlot
  • – Stainless-steel back I/O
  • ASUS Q-Design
  • – Q-Dashboard
  • – Q-DIMM
  • – Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  • – Q-Slot
  • ASUS Thermal Solution
  • – Flexible M.2 heatsink
  • – VRM heatsink design
  • ASUS EZ DIY
  • – ProCool
  • – Pre-mounted I/O shield
  • Aura Sync
  • – Aura RGB header
  • – Addressable Gen 2 headers
  • Software Features: ASUS Exclusive Software
  • Armoury Crate
  • – Aura Creator
  • – Aura Sync
  • – Fan Xpert 2+
  • – Power Saving
  • ASUS AI Advisor
  • ASUS DriverHub
  • ASUS CPU-Z
  • Adobe Creative Cloud (Free Trial)
  • Norton 360 Deluxe (60 Days Free Trial)
  • WinRAR (40 Days Free Trial)
  • UEFI BIOS
  • ASUS EZ DIY
  • – ASUS CrashFree BIOS 3
  • – ASUS EZ Flash
  • – ASUS UEFI BIOS EZ Mode
  • – ASUS MyHotkey
  • BIOS: 2 x 128 Mb Flash ROM, UEFI AMI BIOS
  • Manageability: WOL by PME, PXE
  • Accessories: Cables
  • 2 x SATA 6Gb/s cables
  • Miscellaneous
  • 1 x M.2 rubber package
  • 2 x Screw packages for M.2 SSD
  • 1 x Screw package for M.2 Key E
  • Documentation
  • 1 x Quick start guide
  • Operating System: Windows 11 (22H2 & later), Windows 10 64-bit(21H2 & later)
  • Form Factor: ATX Form Factor
  • 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
