MSI PRO Z890-S WIFI Motherboard

Chipset: INTEL Z890 CPU: Supports Intel(R) Core(TM) Ultra Processors (Series 2): LGA 1851 Memory: 4x DDR5 UDIMM, Maximum Memory Capacity 256GB: Memory Support 8800 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s Onboard Graphics: 1x HDMI(TM): Support HDMI(TM) 2.1, maximum resolution of 4K 60Hz*: 1x DisplayPort: Support DisplayPort 1.4, maximum resolution of 4K 60Hz*: 1x Type-C DisplayPort: Thunderbolt(TM) 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*: *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. Slot: 4x PCI-E x16 slot: PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU): PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset): PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset): PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU) Audio: Realtek(R) ALC897 Codec: 7.1-Channel High Definition Audio Storage: 3x M.2: M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices: M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices: M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices: 4x SATA 6G: : *Please refer to the manual for M.2 SSD heatsink restrictions. RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices: Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices Onboard Thunderbolt: 1x Thunderbolt4 ports (Rear): Supports up to 40Gbps transfer rate with Thunderbolt devices: Supports up to 20Gbps transfer rate with USB4 devices: Supports up to 10Gbps transfer rate with USB 3.2 devices: Supports up to 5V/3A,15W power charging: Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices: Supports up to 8K display USB: 4x USB 2.0 (Front): 6x USB 5Gbps Type A (Rear): 2x USB 5Gbps Type A (Front): 1x USB 20Gbps Type C (Rear): 1x USB 20Gbps Type C (Front) LAN: Realtek(R) 8125D 2.5Gbps LAN Internal IO: 1x Thunderbolt5 card connector(JTBT5, support RTD3): 1x Power Connector(ATX_PWR): 2x Power Connector(CPU_PWR): 1x Power Connector(PCIE_PWR 8pin): 1x CPU Fan: 1x Combo Fan (Pump_Sys Fan): 4x System Fan: 1x EZ Conn-header (JAF_1): 2x Front Panel (JFP): 1x Chassis Intrusion (JCI): 1x Front Audio (JAUD): 1x Tuning Controller connector(JDASH): 3x Addressable V2 RGB LED connector (JARGB_V2): 1x RGB LED connector(JRGB): 1x TPM pin header(Support TPM 2.0): 4x USB 2.0 ports: 2x USB 5Gbps Type A ports: 1x USB 20Gbps Type C ports WIRELESS LAN & BLUETOOTH: Intel(R) Wi-Fi 7: The Wireless module is pre-installed in the M.2 (Key-E) slot: Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps: Supports 802.11 a/ b/ g/ n/ ac/ ax/ be: : Supports Bluetooth(R) 5.4**, MLO, 4KQAM: : * 6GHz band support may depend on every country?s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.: ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor?s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2. LED FEATURE: 4x EZ Debug LED BACK PANEL PORTS: : DisplayPort: USB 5Gbps Type-A: 2.5G LAN: Wi-Fi / Bluetooth: Audio Connectors: HDMI(TM): Thunderbolt(TM) 4 40Gbps (Type-C): USB 20Gbps Type-C: USB 5Gbps Type-A: OPERATING SYSTEM: Support for Windows(R) 11 64-bit BOX CONTENT: PCB Info: ATX: 243.84mmx304.8mm
